xmog_reply Class Reference

Inheritance diagram for xmog_reply:

Public Types
enum	Disposition { SUCCESS = 1, TIMEOUT, COMM_FAILURE }
	The Disposition indicates whether the requested operation was even carried out. If not SUCCESS, the operation was not executed for the indicated reason. If SUCCESS, the rest of the reply's data indicates the actual result of the operation.
enum	{ INIT_BLOCK_SIZE = 4096 }

Public Member Functions
	xmog_reply (Disposition disp, xmog::xmog_message_id t=xmog::NONE, ACE_Message_Block *b=0)
	xmog_reply (const xmog_reply &r)
xmog_reply &	operator= (const xmog_reply &r)
Disposition	disposition (void) const
xmog::xmog_message_id	type (void) const
	type() returns the message reply type. If the disposition is not SUCCESS, this value is meaningless.
virtual bool	matches (const xmog_request *req) const
	Check to see if the specified xmog_request matches this xmog_reply. The reply type needs to match the request type and the JVM pointer needs to match as well. More specific reply types can refine the check as needed.
void	dump ()

Static Public Member Functions
static xmog_reply *	decode (ACE_Message_Block *b)
	Factory function that decodes an incoming reply and creates a xmog_reply-descended reply object. More...

Protected Member Functions
virtual bool	unmarshal (void)
int	readBoolean (bool &b)
	Reads a bool from the message.
int	readByte (jbyte &b)
	Reads a byte from the message.
int	readChar (jchar &c)
	Reads a jchar from the message.
int	readDouble (jdouble &d)
	Reads a jdouble from the message.
int	readFloat (jfloat &f)
	Reads a jfloat from the message.
int	readInt (jint &i)
	Reads a 32bit integer from the message. More...
int	readShort (jshort &s)
	Reads a 16bit integer from the message. More...
int	readLong (jlong &l)
	Reads a 64-bit integer from the message. More...
int	readClassName (char **str)
	Reads a UTF string from the message. More...
int	readUTF (char **str, jint *len=NULL)
	Reads a UTF string from the message. More...
int	readLongUTF (char **str, jint *len=NULL)
	Reads a long UTF string from the message. More...
int	readStringProxy (xmog_remote_java_value &data, xmog::xmog_data_code code)
	Reads a string proxy from the message.
int	read_data_code (xmog::xmog_data_code &code)
	Reads a data code. More...
int	readData (xmog_remote_java_value &data)
	Reads a data object from the message. More...
int	readExc (xmog_remote_java_exception &data)
	Reads an exception from the message. More...
int	readDataProxy (xmog_remote_java_value &data)
	Reads a data proxy object from the message. More...

Constructor & Destructor Documentation

xmog_reply()

xmog_reply::xmog_reply	(	Disposition	disp,
		xmog::xmog_message_id	t = xmog::NONE,
		ACE_Message_Block *	b = 0
	)

Constructor, specifying the reply type and the associated ACE_Message_Block, if there is one.

Parameters

b	ACE_Message_Block pointer with any data associated with the reply. The block's rd_ptr should be pointing to the reply data. Upon return, the xmog_reply owns the block and the caller must no longer refer to it.

Member Function Documentation

decode()

static xmog_reply* xmog_reply::decode ( ACE_Message_Block *  b )

static

Factory function that decodes an incoming reply and creates a xmog_reply-descended reply object.

Parameters

b	Pointer to an ACE_Message_Block containing the raw reply data. The block's rd_ptr is expected to point to the byte following the message's length field. The block's wr_ptr is expected to reflect the end of the reply's data. The created xmog_reply object will control b.

Return values

Pointer

to an xmog_reply object; 0 if an error occurs. If an error occurs, the caller retains control of b. Upon success, the caller must no longer refer to b.

read_data_code()

int xmog_reply::read_data_code ( xmog::xmog_data_code &  code )

protected

Reads a data code.

Parameters

code	the object's code.

readClassName()

int xmog_reply::readClassName ( char **  str )

protected

Reads a UTF string from the message.

Parameters

str	receives the classname in UTF encoding.

readData()

int xmog_reply::readData ( xmog_remote_java_value &  data )

protected

Reads a data object from the message.

Parameters

data	the utility object that will hold that data.

readDataProxy()

int xmog_reply::readDataProxy ( xmog_remote_java_value &  data )

protected

Reads a data proxy object from the message.

Parameters

data	the utility object that will hold that data.

readExc()

int xmog_reply::readExc ( xmog_remote_java_exception &  data )

protected

Reads an exception from the message.

Parameters

data	the utility object that will hold that data.

readInt()

int xmog_reply::readInt ( jint &  i )

protected

Reads a 32bit integer from the message.

This method converts the number from network to host order.

readLong()

int xmog_reply::readLong ( jlong &  l )

protected

Reads a 64-bit integer from the message.

This method converts the number from network to host order.

readLongUTF()

int xmog_reply::readLongUTF ( char **  str, jint *  len = NULL  )

protected

Reads a long UTF string from the message.

Parameters

str	receives the string in UTF encoding. In many cases, developers can directly use this method, which is much faster than the corresponding readString() methods because no conversion has to be performed.
len	an optional pointer to hold the number of bytes that were read.

readShort()

int xmog_reply::readShort ( jshort &  s )

protected

Reads a 16bit integer from the message.

This method converts the number from network to host order.

readUTF()

int xmog_reply::readUTF ( char **  str, jint *  len = NULL  )

protected

Reads a UTF string from the message.

Parameters

str	receives the string in UTF encoding. In many cases, developers can directly use this method, which is much faster than the corresponding readString() methods because no conversion has to be performed.
len	an optional pointer to hold the number of bytes that were read.

---

The documentation for this class was generated from the following file:

• xmog_reply.h
